Clamshells
|
The NB Series of
O.D. Split Frame are one of the most durable in the industry. Due to
a patented bearing system, D.L. Ricci has created a very low profile
machine capable of cutting all wall thickness and alloys of pipe.
The split frame design allows for setup in very restricted areas with
minimal time and effort.
Pipe O.D. ranges that can be machined with the NB Clamshells are from
1.900" to 43.00".
The MC Series of Clamshells is the most stable Split Frame Clamshell
in its class. Capable of severing, beveling, socket weld removal,
and counterboring in pipe or tubing ranging from .50"
to 2.50" O.D
The HD Series of clamshells can handle large diameter pipe and tube
machining with ease. Capable of severing, beveling, boring, and facing
any alloy or wall thickness. Operates either with single or dual drive
systems and choice of hydraulic or air. Pipe O.D. Ranges that can
be machined with the HD Clamshells are from 16.00" to 110.00"
O.D. With its narrow design, the HD Clamshells will fit into areas
other large machines cannot. |
| |
Specifications
|
NB
Series Clamshell
| Model |
Unit
of
Measure |
*
Actual Size |
A |
B |
C |
D |
E |
| NB
4 |
Std
- in
Metric - mm |
1.900
- 4.5
48.3 - 114.0 |
9.25
235 |
4.75
121 |
3
76 |
2.25
57 |
4.5
114 |
| NB
6 |
Std
- in
Metric - mm |
2.375
- 6.625
60.3 - 168.3 |
11.375
289 |
6.875
175 |
3
76 |
2.25
57 |
4.5
114 |
| NB
8 |
Std
- in
Metric - mm |
3.5
- 8.625
88.9 - 219.1 |
13.375
338 |
8.875
225 |
3
76 |
2.25
57 |
4.5
114 |
| NB
10 |
Std
- in
Metric - mm |
4.5
- 10.75
114.3 - 273.1 |
15.75
400 |
11.25
286 |
3
76 |
2.25
57 |
4.5
114 |
| NB
12 |
Std
- in
Metric - mm |
6.625
- 12.75
168.3 - 323.9 |
17.75
451 |
13.25
337 |
3
76 |
2.25
57 |
4.5
114 |
| NB
14 |
Std
- in
Metric - mm |
8.625
- 14
219.1 - 355.6 |
19.75
502 |
14.5
368.3 |
3
76 |
2.25
57 |
4.5
114 |
| NB
16 |
Std
- in
Metric - mm |
8.625
- 16
219.1 - 406.4 |
21
533 |
16.5
419 |
3
76 |
2.25
57 |
4.5
114 |
| NB
18 |
Std
- in
Metric - mm |
12.75
- 18
323.9 - 457.2 |
23
584 |
18.5
470 |
3
76 |
2.25
57 |
4.5
114 |
| NB
20 |
Std
- in
Metric - mm |
14
- 20
355.6 - 508.0 |
25
635 |
20.5
521 |
3
76 |
2.25
57 |
4.5
114 |
| NB
24 |
Std
- in
Metric - mm |
18
- 24
457.2 - 609.6 |
29
737 |
24.5
622 |
3
76 |
2.25
57 |
4.5
114 |
| NB
26 |
Std
- in
Metric - mm |
20
- 26
508.0 - 660.4 |
31
787 |
26.5
673 |
3
76 |
2.25
57 |
4.5
114 |
|
NB 28 |
Std
- in
Metric - mm |
22
- 28
558.8 - 711.2 |
33
838 |
28.5
724 |
3
76 |
2.25
57 |
4.5
114 |
| NB
30 |
Std
- in
Metric - mm |
24
- 30
609.6 - 762.0 |
35
889 |
30.5
775 |
3
76 |
2.25
57 |
4.5
114 |
| NB
36 |
Std
- in
Metric - mm |
30
- 36
762.0 - 914.4 |
41
1041 |
36.5
927 |
3
76 |
2.25
57 |
4.5
114 |
| NB
39 |
Std
- in
Metric - mm |
33
- 39
838.2 - 990.6 |
44
1118 |
39.5
1003 |
3
76 |
2.25
57 |
4.5
114 |
| NB
43 |
Std
- in
Metric - mm |
37
- 43
939.8 - 1092.2 |
48
1219 |
43.5
1105 |
3
76 |
2.25
57 |
4.5
114 |
* The size ranges
listed are for commercial steel pipe
|
MC Series Clamshell
| Model |
Unit
of
Measure |
*
Actual Size |
A |
B |
C |
D |
E |
| MC
1 |
Std
- in
Metric - mm |
.840
- 1.900
21.3 - 48.3 |
5.437
138.1 |
1.625
41.3 |
3.25
82.6 |
1.75
44.5 |
4.312
109.5 |
| MC
2 |
Std
- in
Metric - mm |
.840
- 2.375
21.3 - 60.3 |
6.437
163.5 |
2.625
66.7 |
3.25
82.6 |
1.75
44.5 |
4.312
109.5 |
* The size ranges
listed are for commercial steel pipe
|
HD Series Clamshell
| Model |
Unit
of
Measure |
*
Actual Size |
A |
B |
C |
D |
E |
| HD
28 |
Std
- in
Metric - mm |
16
- 28
406.4 - 711.2 |
38.125
968.4 |
29
736.6 |
5
127 |
4.562
115.9 |
6.75
171.5 |
| HD
30 |
Std
- in
Metric - mm |
18
- 30
457.2 - 762.0 |
40.125
1019.2 |
31
787.4 |
5
127 |
4.562
115.9 |
6.75
171.5 |
| HD
32 |
Std
- in
Metric - mm |
20
- 32
508.0 - 812.8 |
42.125
1070
|
33
838.2 |
5
127 |
4.562
115.9 |
6.75
171.5 |
| HD
36 |
Std
- in
Metric - mm |
24
- 36
609.6 - 914.4 |
46.125
1171.5 |
37
939.8 |
5
127 |
4.562
115.9 |
6.75
171.5 |
| HD
43 |
Std
- in
Metric - mm |
31
- 43
787.4 - 1092.2 |
53.125
1349.4 |
44
1117.6 |
5
127 |
4.562
115.9 |
6.75
171.5 |
| HD
50 |
Std
- in
Metric - mm |
38
- 50
965.2 - 1270.0 |
60.125
1527.2 |
51
1295.4 |
5
127 |
4.562
115.9 |
6.75
171.5 |
| HD
60 |
Std
- in
Metric - mm |
48
- 60
1219.2 - 1524 |
70.325
1786.3 |
61
1549.4 |
5
127 |
4.562
115.9 |
6.75
171.5 |
| HD
80 |
Std
- in
Metric - mm |
62
- 80
1574.8 - 2032.0 |
90.325
2294.3 |
81
2057.4 |
5
127 |
4.562
115.9 |
6.75
171.5 |
| HD
110 |
Std
- in
Metric - mm |
82
- 110
2082.8 - 2794.0 |
120.325
3056.3 |
111
2819.4 |
5
127 |
4.562
115.9 |
6.75
171.5 |
* The size ranges
listed are for commercial steel pipe
|
